SEMA 2013 Engines

This year at the 2013 SEMA Show, Gale Banks Engineering showed off some of the engines that we have worked on throughout the years. There was the engine out of our famous Banks Sidewinder Dakota, the World’s Fastest Diesel Truck! And there were some of the diesel engines found in many popular trucks on the road today. But most noteable was the new powertrain options that will soon be available to the public.

Gale Banks Engineering displays powertrain solutions at SEMA Show 2013

November 2013 — This year at the 2013 SEMA Show, Gale Banks Engineering showed off some of the engines that we have worked on throughout the years. There was the engine out of our famous Banks Sidewinder Dakota, the World’s Fastest Diesel Truck! And there were some of the diesel engines found in many popular trucks on the road today. But most notable was the new powertrain options that will soon be available to the public. Gale Banks Engineering has been producing these engines in different forms for a while now, and will soon be making them available to you. Read more about each of the engines that we took to the show, and if you want to find out more, give us a call (877) 455-2315.

866T 6.6L V-8 Diesel HD 2WD Package
Gale Banks 866T

6.6L V-8 Diesel HD 2WD Package
Fuel: Diesel, DF2, Jet-A, JP-8

Power Rating: 275-575HP / 3000-3800 RPM
Total Powertrain Weight: 1,123 lbs

Features:
Banks 6745E 6-Speed automatic transmission
AutoMind® Electronic Diesel Controller & CAN-networked Transmission Controller
Banks Severe Duty Crankshaft Vibration Dampener & Accessory Drive w/ 200A alternators
Banks SpeedBrake Integrated exhaust brake
Banks Multi-plate Lockup Torque Converter
Techni-Cooler® intercooler

Component Dry Weights:
Engine: 912 lbs w/o accessories
Transmission: 211 lbs w/ 300mm converter
Banks 6745E 6-Speed auto-transmission:
First Gear: 4.03:1
Sixth Gear: 0.67:1
Overall Gear Spread: 6.01

866T 6.6L V-8 Diesel HD 2WD Package

630T 3.0L V-6 Diesel 4WD Package
Gale Banks 630T

3.0L V-6 Diesel HD 4WD Package
Fuel: Diesel, DF2, Jet-A, JP-8

Power Rating: 221-268HP / 4000 RPM
Total Powertrain Weight: 845 lbs

Features:
Banks 6745E 6-Speed automatic transmission
Banks 24535E Dual-Range Transfer Case
AutoMind® Electronic Diesel Controller & CAN-networked Transmission Controller
Banks Severe Duty intake manifold
Banks Severe Duty Crankshaft Vibration Dampener & Accessory Drive w/ 210A alternator
Banks Multi-plate Lockup Torque Converter
Techni-Cooler® intercooler

Component Dry Weights:
Engine: 535 lbs w/o accessories
Transmission: 218 lbs w/ 300mm converter
Transfer Case: 92 lbs w/ adapter (9lbs)
Banks 6745E 6-Speed auto-transmission:
First Gear: 4.03:1
Sixth Gear: 0.67:1
Overall Gear Spread: 6.01

630T 3.0L V-6 Diesel 4WD Package

Banks Gen II SBC Sidewinder® Twin-Turbo Gasoline Engine
Banks Gen II SBC
Sidewinder® Twin-Turbo

Fuel: Gasoline

800 HP 383 cubic inch Pump Gas
Ready-to-Run Package Shown
Up to 1,115 HP / 6800 RPM available

Features:
Sidewinder® Twin-Turbo System
Straight-Shot™ Water-Methanol Injection
Holley HP Return-Type Fuel Supply System
Sidewinder-specific Comp Cams Hydraulic Roller Cam
Dart Iron Block & Forged Internals
Aluminum Heads w/Stainless Valves & Roller Rockers
SFI certified Dampener & Flexplate standard, Flywheel available
Optional Billet Serpentine Drive Accessory System
Polished finish on all components available

Controls:
Holley HP Throttle Body EFI w/120 lb-hr injectors
Holley Distributorless Ignition System w/crank trigger
Dual Knock Sensors standard
Optional Dual Wideband Oxygen Sensors shown
Optional Integrated Transmission Control
w/Dominator ECU


Banks Sidewinder® 5.9L Cummins Bonneville Race Engine
Banks Sidewinder®
5.9L Cummins

Bonneville Race Engine
Fuel: Diesel

FIA Land Speed Record: Bonneville
Oct. 19, 2002 — 217.306 mph
(Still stands in 2013)

Features:
Big Hoss® intake manifold
Banks Shape-Shifter Variable-Geometry Turbo
Big Hoss® 24v Ported Head
PowerStick® Camshaft
Banks Billet™ Torque Converter
TorqueTube® Header


866T 6.6L V-8 Diesel Marine Package
Gale Banks 866T

6.6L V-8 Diesel Marine Package
Fuel: Diesel, DF2, Jet-A, JP-8

Power Rating: 350-575HP / 3000-3800 RPM
Weight: 1300 lbs w/accessories, coolers

Features:
AutoMind® Electronic Diesel Controller
Severe Duty Crankshaft Vibration Dampener
Accessory Drive w/160A 12V/24V alternator
Fresh Water cooled exhaust system w/single turbocharger
Sea Water cooled Techni-Cooler®
Intercooler/Intake manifold
Severe Duty Valve Covers with Walker CCV system
Bell-housing with top-mount starter


GM 6.6L Duramax
GM 6.6L Duramax

Fuel: Diesel

Features:
Banks iQ®
AutoMind® programmer
Ram-Air® intake
Super-Scoop®
Double-Shot™ injection
Techni-Cooler® intercooler
SpeedBrake™ engine brake


Cummins 5.9L ISB
Cummins 5.9L ISB

Fuel: Diesel

Features:
Double-Shot™ injection
EconoMind® tuner
Monster-Ram® intake elbow
Banks Billet intake heater delete
Ram-Air® intake
Super-Scoop®
Techni-Cooler® intercooler
SpeedBrake™ engine brake


Ford 6.0L Power Stroke Diesel Engine
Ford 6.0L Power Stroke

Fuel: Diesel

Features:
Double-Shot™ injection
Six-Gun® tuner
Ram-Air® intake
High-Ram® intake elbow
Techni-Cooler® intercooler
SpeedBrake™ engine brake


Ford F-150 5.4L V-8
Ford F-150 5.4L V-8

Fuel: Gasoline

Features:
Banks iQ®
AutoMind® programmer
Ram-Air® intake
High-Ram® intake elbow
Straight-Shot™ injection
TorqueTube® exhaust manifold
Monster® Exhaust


For more information on our powertrain options, call (877) 455-2315
