Custom Airboxes | BANKS BUILT Ep 30

Powering Lokjaw will be a Supercharged 6.6L DURAMAX that requires an abundance of air, which will require custom airboxes. Erik and Matt get to work on modifying the radiator core support that houses two custom-fabricated intake air boxes with Banks Big Ass Filters. These airboxes will have an inlet through the grill that will ram air into the air boxes and into our Whipple Supercharger giving LokJaw the air it will need to reach our horsepower goal.

00:00 Intro
00:36 Erik preps for LokJaw
01:53 Fitting radiator to core support
03:05 Mounting the LTR and a/c condenser
04:50 CAD review brackets for LTR and ACC
05:12 Fabricating brackets for LTR and ACC
06:14 Erik reviews Matt’s design
09:30 Erik fabricated air boxes
13:59 Erik modifies radiator core support
18:38 Next episode teaser

Matt Gamble uses CAD to create brackets for the LRT and AC condenser which are then 3-D printed. After they’re done printing, Erik bends them up to prepare for installation. One of the big challenges is figuring out how to do the custom airboxes through the radiator core support on each side. Plus, we have to fit in the Ram-Air.

The episode wraps up with a teaser for next week’s episode.
